The Beetek Display Port DP 1.2 and HDMI 2.0 Fibre Extender lets you send 4K@60Hz 4:4:4 video up to 300 metres over a single fibre optic cable—perfect for broadcast studios, live events, and edit suites where you need to keep your workstation in one spot and displays in another. It handles dual video inputs (HDMI and DisplayPort), plus USB, Ethernet, and audio, so you can extend everything at once without lag or quality loss. EDID management automatically optimises output for your monitors.

Product Name	One core single mode DP1.2 / HDMI2.0 fiber extender
Model	M1-DP&HDMI-Pro
Brand	Beetek
Signal	DP1.2, HDMI2.0
Input Connector	TX: HDMI Type A Female, DP Female, UBS Type A Female, RJ45 2, XLR Female 2 ; RX: Single-core LC
Output Connector	TX : Single-core LC RX: HDMI Type A Female, DP Female, UBS Type A Female 2, RJ452, XLR *2
Locking Connector	Yes
Fiber Interface Dust Prevention	Yes
Fiber Type	Single-mode G657.A1
Indicator LED	Signal, Power, Network port, EDID, Status and Hot-plug 6 way Indicator
Rack Mountable	Yes (standard 1U rack mount)
Anti-slip pad	Yes
Locking power connector	Yes
Waterproof power connector	Yes (NEUTRIK waterproof power connector)
Daisy-chainable power	Yes
Power Consumption	AC 100-250V
Ambient Temp	-20°C ~ 70°C
Material	Aluminum alloy mold
Dimensions	TX: 220 150 41mm； RX: 220 150 41mm
Weight	TX: 1.20kg; RX: 1.25kg
Package Dimensions	274 252 212mm
Package Weight	3.65kg
EDID Switch (TX)	Learn button and mode dial
EDID Modes	Pass-through, learn and Internal
DDC	Yes
AUX	Yes
De-embedding (RX)	Audio de-embedding toggle switch
Independent USB	Supports independent USB1.1 transmission
Audio De-embedding	Yes
Independent audio	Supports independent stereo audio transmission
Independent Ethernet	Supports bidirectional 100M Ethernet
DP transmission	Supports independent DP signal transmission
HDMI transmission	Supports HDMI signal transmission
HDMI to DP	Supports TX HDMI input to RX DP output
DP to HDMI	Supports TX DP input RX HDMI output
HDMI Audio	Supports extended HDMI audio
3D	Yes
CEC	Supports in EDID pass-through mode
ARC	Supports in EDID pass-through mode
HDCP	Supports HDCP2.2 in EDID pass-through mode
XvYCC Color Space	Yes
HDR	Yes
BT.2020 Color Space	Yes
Optical Module	410G ，22.5G 6-channel single-mode optical module
Technical Characteristics	6-wave CWDM Technology
Optical module life	100,000 Hours
Resolution	3840x2160@60Hz
Transmission Distance	Single-mode 300M
Clock Bandwidth	600MHz 3 / 540MHz 4
Transmission Speed	21.6Gbps
Balancing Chip	Automatic equalization
Reclocking	Yes
ESD Protection	Yes
Hot Plug	Yes
Delay	Zero-frame
Compression	None
Sampling Rate	Bandwidth Range: 8~16bit
Sampling Ratio	RGB 4:4:4 , YUV 4:4:4, YUV 4:2:2, YUV 4:2:0
