Blackmagic Design ATEM 2 M/E Constellation 4K Live Production Switcher (1 RU)

Name: Blackmagic Design ATEM 2 M/E Constellation 4K Live Production Switcher (1 RU)
Brand: Blackmagic Design
SKU: BLA-SWATEMSCN2-2ME2-4K
Price: 5952.00 AUD
Availability: InStock

Blackmagic Design | SKU: BLA-SWATEMSCN2-2ME2-4K | Barcode: 4000001565481

$5,952.00 $6,445.00

Tax included Shipping calculated at checkout.

Videocraft Melbourne

Out of Stock. Backorder available

148 Highbury Road, Burwood VIC 3125
03 9273 7500

Videocraft Sydney

Out of Stock. Backorder available

20/39 Herbert Street, St Leonards NSW 2065
02 9462 8600

Shipping Options

Shipping Methods & Estimated Delivery Times

Australia Post Express Shipping – 1–2 business days within the same state, 1–3 business days interstate.
Australia Post Regular Shipping – 2–4 business days within the same state, 3–6 business days interstate.
StarTrack Express – 2–7 business days, depending on location.
StarTrack Premium – Next business day between capital cities and major metro areas.
Local On-Demand Delivery (Small Orders Only) – Same-day delivery within Melbourne & Sydney metro areas using Uber and Yello.

Shipping Cut-Off Time: Orders placed before 2 PM will typically be processed and dispatched the same day.

Please note: **We ship orders as a single shipment. If your order contains items with different availability, your order will be held until all items are ready to be shipped together.** Keep this in mind when placing your order. If this is an issue, please contact us at websales@videocraft.com.au to arrange for alternative shipping options.

The Blackmagic Design ATEM 2 M/E Constellation 4K Live Production Switcher (1 RU) adds UHD 4K capabilities and 12G-SDI ports to the familiar switcher construction of its predecessor. Designed for powerful live event UHD 4K switching, the unit features 20 individual 12G-SDI inputs that support 12G/3G/HD-SDI signals and deliver them to 12 12G-SDI outputs or webcam USB-C output. In addition, the switcher has a multiview output with up to 16 routable windows that can display inputs, keyed video, graphics, and stills from the media pool, as well as the program output. Each input connects to a built-in Fairlight audio mixer supporting up to 28 channels of audio.

Available M/E Layers	2 M/E
Effect Types	8x Chroma Key 11x Luma Key 2x DVE, Stinger 2x DVE
Downstream Keys	2x Chroma, Luma, DVE
Generators	2x Color 11x Pattern
Audio Mixing	48-Channel Mixing

Processing

Switching Type	Pushbutton, Software
Latency	10 Lines
Processing Resolution	UHD 4K
Color Processing	10-Bit 4:2:2

Input

Number of Video Input Sources	20
Video Inputs	20x BNC (12G-SDI) Female
Input Video Format	SDI UHD 4K at 23.98/24/25/29.97/30/50/59.94/60 fps 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps
Audio Inputs	2x 1/4" TRS
Embedded Audio Input	SDI: 16-Channel

Output

Video Output Channels	12
Video Outputs	12x BNC (12G-SDI) Female
Output Video Format	SDI UHD 4K at 23.98/24/25/29.97/30/50/59.94/60 fps 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps 1080i at 50/59.94/60 fps 720p at 50/59.94/60 fps
Embedded Audio Output	SDI: 16-Channel
Multiview Output	16-Way Multiview

Connectivity

Other I/O	1x USB-C 1x XLR 5-Pin Talkback Input 1x XLR 5-Pin Talkback Output 1x RJ45 Control, LAN Input/Output 1x RJ45 Talkback Input/Output 1x BNC Blackburst, Reference, Tri-Level Sync Input
Video Standard Compliance	SMPTE 292M/296M/424M/424M-A/424M-B/ST 2081-10/ST-2081-1/ST-2082-1/ST-2082-10

Display

Display Size

2.2"

Hardware

OS Compatibility	Windows 10 to 11 macOS 13.0 to 14.0
Processor	Not Specified by Manufacturer
Wi-Fi	Yes
Bluetooth	No
Power I/O	1x IEC C13 Input
Power Consumption	Device: 100 to 240 VAC (90 W)

Environmental

Operating Temperature	32 to 104¬∞F / 0 to 40¬∞C
Storage Temperature	-4 to 140¬∞F / -20 to 60¬∞C
Operating Humidity	0 to 90%

General

Rack Form Factor	1 RU
Dimensions	19 x 9.22 x 1.74" / 48.3 x 23.42 x 4.42 cm
Weight	6.55 lb / 2.97 kg
