| Format | Lens mount RF mount |
| Image processor | DIGIC X |
| Compatible lenses | RF/RF-S lenses (EF/EF-S lenses with EF-EOS R) |
| Image sensor | Full frame |
| Effective pixels (max. approx. megapixels) | 32.5MP |
| Self-cleaning sensor unit | Yes |
| Recording media | Card slot Dual slots
Card 1 CFexpress Type B
Card 2 SDXC / SDHC / SD (UHS-II compatible) |
| Record function + card/folder selection | Separate recording of still photos and movies |
| Still photo recording function | Standard / Auto switch card / Record separately / Record to multiple |
| Movie recording function | Standard / Relay recording / Main・Proxy / Main・Sub / Rec. to multiple |
| Still photo recording Image quality | JPEG/HEIF Yes / Yes
RAW/C-RAW Yes / Yes
Dual Pixel RAW |
| Maximum burst (Approx.)*1 | Mechanical shutter / Electronic first-curtain
JPEG Large / Fine
RAW 150
Electronic shutter JPEG Large / Fine 330
RAW 150 |
| Movie recording Format | XF-HEVC S / XF-AVC S |
| Recording format | RAW Yes
HEVC YCC422 10 bit / YCC420 10 bit
AVC YCC422 10 bit / YCC420 8 bit |
| Movie recording size Resolution | RAW / 4K-D / 4K-U / 2K-D / Full HD |
| Frame rate (fps) | 179.8 / 150.0 / 119.9 / 100.0 / 59.94 / 50.00 / 29.97 / 25.00 / 24.00 / 23.98 |
| RAW format | Standard RAW / Light RAW |
| Compression method | High Quality Intra / Standard Intra / Light Intra / Standard LGOP / Light LGOP |
| Oversampling | 60p 4K movies from approx. 5.9K oversampling
30p 4K movies from approx. 7K oversampling |
| Open Gate | Yes |
| Slow & Fast Motion (S&F) movies | Yes |
| High Frame Rate movies (S&F movies) | Yes |
| Movie cropping | Yes |
| HDR movie mode | Yes |
| Time-lapse movies | 4K / Full HD Yes / Yes |
| Smooth skin movie / Movie for close-up demos / Movie IS mode / HDR movies | Yes / Yes / Yes / Yes |
| Audio format | LPCM / 24 bit / 4CH, ACC / 16 bit / 2CH |
| Built-in microphone | Stereo |
| Built-in cooling fan | Yes |
| Pre-recording | Yes |
| Tally lamp / Recording emphasis | Yes / Yes |
| Maximum recording time per recording 59.94 fps or less | 6 hr. |
| HDMI RAW output | Yes |
| Dual shooting (still & movie) | Yes |
| White balance Shockless WB | Yes |
| Flash WB Fixed at 6000 K | Yes |
| AWB response | Yes |
| AWB lock | Yes |
| Picture Style | Yes |
| Color filter | Yes |
| Custom Picture (movies) / Canon Log 2 / Canon Log 3 | Yes / Yes / Yes |
| Auto Lighting Optimizer | Yes |
| Highlight tone priority | Yes |
| Long exposure noise reduction | Yes |
| High ISO speed noise reduction | Yes |
| Lens aberration correction | Yes |
| Focus breathing correction (movies) | Yes |
| AF Focusing brightness range (with an f/1.2 lens, center AF point, One-Shot AF, at room temperature, and ISO 100) * Except RF lenses with a Defocus Smoothing (DS) coating | Still photo EV -6.5 ～ 21
4K 30p EV -4.0 ～ 21
2K 30p EV -4.0 ～ 21 |
| AF operation One-Shot AF | Yes |
| AI Focus AF | Yes |
| Servo AF / Movie Servo AF | Yes / Yes |
| No. of AF areas available for auto selection (max. zones) | 1053 |
| AF area (AF method) Spot AF / 1-point AF | Yes |
| Expand AF area | Yes |
| Flexible Zone AF | Yes |
| Whole area AF | Yes |
| Whole area tracking OFF | Yes |
| Servo AF characteristics (still photos) Case Auto / Manual Subject to detect Auto | Yes |
| People / Animals / Vehicles | Yes / Yes / Yes |
| Eye detection | Yes |
| Track after Focusing (movies) | Yes |
| Register people priority | Yes |
| Action priority | Yes |
| Screen size | 3 |
| Dot count (approx.) | 1.62 million dots |
| Screen brightness / colour tone | 7 levels / 4 modes |
| Vari-angle | Yes |
| Display simulation | Yes |
| Optical viewfinder simulation (View assist) HDR / C.Log View Assist | Yes |
| Zebra settings / False colour / Waveform monitor setting (movies) | Yes / Yes / Yes |
| Aspect marker | Yes (Marker 1, 2) |
| Rotating shooting info display (movies) | Yes |
| HDMI resolution | Auto / 1080p / 1080i |
| Shooting mode Still photo shooting | A+ / SCN / Fv / P / Tv / Av / M / C1 / C2 / C3 |
| Movie recording | A+ / Movie for close-up product demo / SCN / P / Tv / Av / M / S&F / C1 / C2 / C3 |
| Number of metering sensor zones (still photos) | 384 zones (24×16) |
| Metering brightness range (at room temperature, ISO 100) Still photo | EV -3 to 20 |
| Metering brightness range (at room temperature, ISO 100) Movie | EV -1 to 20 |
| Anti-flicker shooting | Yes |
| High-frequency anti-flicker shooting | Yes |
| ISO speed (still photos) Normal speeds | 100 to 64000 |
| Expanded speeds (max. equivalent) | L: 50, H: 102400 |
| ISO speed (movies) Normal speeds | 100 to 25600 (Custom Picture: Off) |
| Expanded speeds (max. equivalent) | H: 32000 / 40000 / 51200 / 64000 / 102400 (Custom Picture: Off) |
| Shutter speed (still photos/sec.) Mechanical shutter / Electronic first-curtain / Electronic shutter | 1/16000–30 sec., bulb |
| Shutter speed (movies/sec.) Electronic shutter | 1/8000–1/8 |
| Flash sync speed (sec.) Mechanical shutter / Electronic 1st-curtain / Electronic shutter / Sync speed priority | Yes |
| Durability (with mechanical shutter) | Yes |
| Silent shutter function | Yes |
| Multiple-exposure shooting | Yes |
| HDR shooting (PQ): still photos / movies | Yes / Yes |
| HDR mode (still photos) | Yes |
| HDR movie mode | Yes |
| Focus bracketing | Yes |
| Image stabilisation function Camera in-body IS | Yes |
| Coordinated control | Yes |
| IS effectiveness, in number of stops (still photos) | Center: 7.5 stops, Peripheral: 7.0 stops *Yaw, pitch, and roll correction performance based on the CIPA 2024 standard *RF24-105mm F2.8 L IS USM Z (coordinated control), f = 105 mm |
| Movie digital IS | Yes |
| Subject tracking IS | Yes |
| Subject blur guide Peripheral coordinated control | Yes |
| Movie auto level | Yes |
| Operating mode (Mode A / B / C) | Continuous shooting speed (High-speed continuous shooting +, max. approx. shots/sec.) Mechanical shutter / Electronic 1st-curtain / Electronic shutter 40 |
| Pre-continuous shooting | Yes |
| RAW image processing | Yes |
| Dual Pixel RAW processing | Yes |
| In-camera upscaling | Yes |
| Customise buttons for shooting/playback | Yes / Yes |
| Customise dials/control ring | Yes |
| Digital terminal | USB Type-C |
| HDMI output terminal | Type A |
| External microphone input terminal | Yes |
| Headphone terminal | Yes |
| Multi-function shoe | 21-pin / 5-pin Yes / |
| Battery | LP-E6P*² |
| USB power support Battery charging and camera power supply | Yes / Yes |
| AC power source | DR-E6P + PD-E2 |
| Number of available shots*³ (approx., with power saving, at 23℃) | 640 |
| Weather sealing | Yes |
| VR lenses Support for RF5.2mm F2.8 L DUAL FISHEYE | Yes |
| Wi-Fi (wireless LAN) | Equivalent to IEEE 802.11b/g/n/a/ac |
| Transmission frequency (Center frequency) | 2.4 GHz / 5 GHz |
| Bluetooth Specification | Version 5.1 |
| USB | Equivalent to USB 10 Gbps (SuperSpeed Plus USB / USB 3.2 Gen 2) |
| FTP transfer (wireless LAN) | Yes |
| Live streaming USB (UVC/UAC) connection | Yes |
| HDMI connection | Yes |
| Camera Connect Live Switcher Mobile | Yes |
