Cameras

RED V-RAPTOR XL 8K VV Digital Cinema Camera in V-Mount

Name: RED V-RAPTOR XL 8K VV Digital Cinema Camera in V-Mount
Brand: RED
SKU: RED-RaptorXL-Body
Price: 74915.01 AUD
Availability: InStock

RED | SKU: RED-RaptorXL-Body | UPC: 810016942092

$74,915.01

Tax included Shipping calculated at checkout.

Shipping Options

Shipping Methods & Estimated Delivery Times

Australia Post Express Shipping – 1–2 business days within the same state, 1–3 business days interstate.
Australia Post Regular Shipping – 2–4 business days within the same state, 3–6 business days interstate.
StarTrack Express – 2–7 business days, depending on location.
StarTrack Premium – Next business day between capital cities and major metro areas.
Local On-Demand Delivery (Small Orders Only) – Same-day delivery within Melbourne & Sydney metro areas using Uber and Yello.

Shipping Cut-Off Time: Orders placed before 2 PM will typically be processed and dispatched the same day.

Please note: **We ship orders as a single shipment. If your order contains items with different availability, your order will be held until all items are ready to be shipped together.** Keep this in mind when placing your order. If this is an issue, please contact us at websales@videocraft.com.au to arrange for alternative shipping options.

The RED V-RAPTOR XL 8K VV Digital Cinema Camera in V-Mount features up to 8K VV multiformat video capture, REDCODE raw and Apple ProRes recording, and 1080p streaming in a streamlined form featuring an array of interfaces suitable for high end crew use. This follow-up to the V-RAPTOR incorporates internal ND filters and an interchangeable lens mount, and it includes an ARRI PL mount. Its industry-standard interface incorporates three 12G/6G/3G-SDI outputs, both 12 and 24V power outputs, timecode and genlock ports, and a V-mount battery plate.

Built-In Pro Interfaces

Designed for professional crew use with integrated auxiliary power and mounting points for attaching multiple high-end camera accessories
Built-in wireless genlock and timecode
Multiple video outputs, including 12G/6G/3G-SDI

Interchangeable Lens Mount

Includes an ARRI PL lens mount which can be swapped for a separately available Canon EF mount, enabling you to make use of a large variety of lenses

Internal ND Filters

Motorized clear and 2 to 7-stop ND filters with 1/3, 1/4, and 1-stop increments provide precision exposure control

Streamlined Form

The built-in interfaces lend the V-RAPTOR XL camera rig a streamlined, accessible form

Imaging

Lens Mount	ARRI PL
Sensor Resolution	Effective: 35.4 Megapixel (8192 x 4320)
Sensor Type	40.96 x 21.6 mm (Vistavision) CMOS
Image Stabilization	None
Built-In ND Filter	Mechanical Filter Wheel with Clear, 2 Stop (1/4), 3 Stop (1/8), 4 Stop (1/16), 5 Stop (1/32), 6 Stop (1/64), 7 Stop (1/128) ND Filters
Internal Filter Holder	No
Capture Type	Video Only

Exposure Control

Shutter Type	Electronic Rolling Shutter
Advertised Dynamic Range	17 Stops

Internal Video Capture

Raw Recording	REDCODE RAW 8192 x 4320 up to 119.88 fps 7168 x 3780 up to 140 fps 6144 x 3240 up to 160 fps 5120 x 2700 up to 192 fps 4096 x 2160 up to 240 fps 3072 x 1620 up to 320 fps 2048 x 1080 up to 480 fps
Recording Modes	REDCODE HQ 8192 x 4320 up to 59.94p 6144 x 3240 up to 96p 4096 x 2160 up to 240p 2048 x 1080 up to 480p REDCODE MQ 8192 x 4320 up to 59.94p 6144 x 3240 up to 160p 4096 x 2160 up to 240p 2048 x 1080 up to 480p REDCODE LQ 8192 x 4320 up to 119.88p 6144 x 3240 up to 160p 4096 x 2160 up to 240p 2048 x 1080 up to 480p
Sensor Crop While Recording	8K (8192 x 4320) in 2:1 / 2.4:1 / 16:9 / 17:9 When Recording in Raw 8K (8192 x 4320) in 1.25:1 / 1.3:1 / 1.5:1 / 1.6:1 / 1.8:1 / 2:1 When Recording in Raw / Anamorphic 7K (7168 x 3780) in 2:1 / 2.4:1 / 16:9 / 17:9 When Recording in Raw 7K (7168 x 3780) in 1.6:1 / 1.8:1 / 2:1 When Recording in Raw / Anamorphic 6K (6144 x 3240) in 2:1 / 2.4:1 / 16:9 / 17:9 When Recording in Raw 6K (6144 x 3240) in 1.25:1 / 1.3:1 / 1.5:1 When Recording in Raw / Anamorphic 5K (5120 x 2700) in 2:1 / 2.4:1 / 16:9 / 17:9 When Recording in Raw 4K (4096 x 2160) in 2:1 / 2.4:1 / 16:9 / 17:9 When Recording in Raw 3K (3072 x 2160) in 2:1 / 2.4:1 / 16:9 / 17:9 When Recording in Raw 2K (2048 x 1080) in 2:1 / 2.4:1 / 16:9 / 17:9 When Recording in Raw
Variable Frame Rates	8K: Up to 119.88 fps 8K (Windowed): Up to 150 fps 7K: Up to 140 fps 7K (Windowed): Up to 175 fps 6K: Up to 160 fps 6K (Windowed): Up to 200 fps 5K: Up to 192 fps 5K (Windowed): Up to 240 fps DCI 4K: Up to 240 fps DCI 4K (Windowed): Up to 300 fps 3K: Up to 320 fps 3K (Windowed): Up to 400 fps DCI 2K: Up to 480 fps DCI 2K (Windowed): Up to 600 fps
Gamma Curve	RED IPP2
Recording Limit	Unlimited
Built-In Microphone Type	Mono
Audio Recording	2-Channel 24-Bit 48 kHz

External Video Capture

External Recording Modes	None
IP Streaming	MJPEG: 1920 x 1080

Interface

Media/Memory Card Slot	Single Slot: CFexpress Type B (CFast 2.0)
Video I/O	3 x BNC (12G-SDI) Monitor Output 1 x BNC (3G-SDI) Monitor Output 1 x Proprietary Monitor Output
Audio I/O	1 x LEMO 5-Pin Mic/Line (+48 V Phantom Power) Input 1 x 1/8" / 3.5 mm TRS Stereo Headphone Output
Power I/O	1 x LEMO 4-Pin (19.5 to 34 VDC) Input 2 x D-Tap (12 VDC up to 3 A) Output 1 x LEMO 2-Pin (12 VDC at 3 A) Output 1 x LEMO 2-Pin (12 VDC at 1.5 A) Output 1 x LEMO 2-Pin (12 VDC at 1 A) Output 2 x Fischer 3-Pin (12 VDC up to 3 A) Output
Other I/O	1 x BNC (Genlock) 1 x LEMO 5-Pin (Timecode) 1 x 9-Pin (Ethernet) Control/Data Input/Output 1 x USB Type-C
Wireless	2.4 / 5 GHz Wi-Fi Video Output
Global Positioning (GPS, GLONASS, etc.)	None

Monitor

Size	2.4"
Display Type	Fixed LCD

Viewfinder

Type	Optional, Not Included

Focus

Focus Type

Auto and Manual Focus

Environmental

Operating Temperature	32 to 104°F / 0 to 40°C
Storage Temperature	-4 to 122°F / -20 to 50°C
Storage Humidity	0 to 85%

General

Battery Type	V-Mount
Tripod Mounting Thread	None
Material of Construction	Aluminum
Dimensions (W x H x D)	Not Specified by Manufacturer
Weight	7.99 lb / 3.62 kg
