Beetek Single-core LC DP 1.4 Single-mode fiber extender +IR + 232

Name: Beetek Single-core LC DP 1.4 Single-mode fiber extender +IR + 232
Brand: Beetek Technology
SKU: BEE-M1-DP14RR
Price: 3135.00 AUD
Availability: InStock

Beetek Technology | SKU: BEE-M1-DP14RR | Barcode: 880106

$3,135.00

Tax included

Store Availability

Melbourne (Burwood) Out of Stock

▼

Out of Stock. Place a Backorder

📍 148 Highbury Road, Burwood, VIC 3125

☎ 03 9273 7500 • Get directions

Sydney (St Leonards) Out of Stock

▼

Out of Stock. Place a Backorder

📍 20/39 Herbert Street, St Leonards, NSW 2065

☎ 02 9462 8600 • Get directions

Shipping Options

Shipping Methods & Estimated Delivery Times

Australia Post Express Shipping – 1–2 business days within the same state, 1–3 business days interstate.
Australia Post Regular Shipping – 2–4 business days within the same state, 3–6 business days interstate.
StarTrack Express – 2–7 business days, depending on location.
StarTrack Premium – Next business day between capital cities and major metro areas.
Local On-Demand Delivery (Small Orders Only) – Same-day delivery within Melbourne & Sydney metro areas using Uber and Yello.

Shipping Cut-Off Time: Orders placed before 1 PM will typically be processed and dispatched the same day.

Please note: **We ship orders as a single shipment. If your order contains items with different availability, your order will be held until all items are ready to be shipped together.** Keep this in mind when placing your order. If this is an issue, please contact us at websales@videocraft.com.au to arrange for alternative shipping options.

The Beetek Single-core LC DP 1.4 Single-mode Fibre Extender is a professional-grade signal extension solution that transmits uncompressed DisplayPort 1.4 video up to 8K at 60Hz (4:4:4 colour sampling) over distances up to 300 metres via single-mode fibre optic cable. Using CWDM multiplexing technology, it delivers true zero-latency, zero-compression transmission at 32.4 Gbps bandwidth—critical for colour-accurate work in broadcast, live production, and high-end post workflows. It includes bidirectional RS232 and IR pass-through for remote device control, making it ideal for live events, rental houses, OB trucks, and edit suites where you need to position workstations or displays far from source equipment without signal degradation.

Product Name	One core single mode DP 1.4 Fiber Extender +IR+232
Model	M1-DP14Rr
Signal	DP1.4
Input Connector	TX： DP female, IR, RS-232; RX：Single-core LC
Output Connector	TX：Single-core LC ; RX：DP female, IR, RS-232
Fiber type	Single-mode G657.A1
Indicator LED	Signal, Power, Mode, Hot-plug detect
Locking power connector	Yes
Power Consumption	DC 12V 2A
Ambient Temp	-20°C ~ 70°C
Material	Metal mold
Dimensions	TX:160 85 26mm; RX:160 85 26mm;
Weight	TX 0.45kg; RX0.45
Package Dimensions	226 160 121mm
Package Weight	1.3kg
AUX Channel	Yes
IR	2-way IR
RS-232	2-way RS-232
High-speed Ethernet	Supports expanded high-speed Ethernet
Extended USB	Supports extended USB2.0/USB3.1
Extended Audio	Supports 32 extended audio channels
3D	Yes
CEC	Yes
ARC	Yes
HDCP	HDCP2.2
HDR	Yes
BT.2020 Color space	Yes
Optical Module	412G＋22.5G 6-channel Single-mode Optical Module
Technical Characteristics	6-wave CWDM Technology
Optical Module Life	100,000 Hours
Resolution	7680X4320@30Hz
Transmission Distance	Single-mode 300M
Clock Bandwidth	810MHz * 4
Transmission Speed	32.4Gbps
Balancing Chip	Automatic equalization
ESD Protection	Yes
Hot Plug	Yes
Delay	Zero-frame
Compression	None
Sampling Rate	Bandwidth Range: 8~16bit
Sampling Ratio	RGB 4:4:4, YUV 4:4:4+B4:D44, YUV 4:2:0, YUV 4:2:0
