Roland VP-42H Video Processor

Name: Roland VP-42H Video Processor
Brand: Roland
SKU: ROL-VP42H
Price: 1995.00 AUD
Availability: InStock

Roland | SKU: ROL-VP42H | Barcode: 4000001514113

$1,995.00 $2,299.00

Tax included Shipping calculated at checkout.

Shipping Options

Shipping Methods & Estimated Delivery Times

Australia Post Express Shipping – 1–2 business days within the same state, 1–3 business days interstate.
Australia Post Regular Shipping – 2–4 business days within the same state, 3–6 business days interstate.
StarTrack Express – 2–7 business days, depending on location.
StarTrack Premium – Next business day between capital cities and major metro areas.
Local On-Demand Delivery (Small Orders Only) – Same-day delivery within Melbourne & Sydney metro areas using Uber and Yello.

Shipping Cut-Off Time: Orders placed before 2 PM will typically be processed and dispatched the same day.

Please note: **We ship orders as a single shipment. If your order contains items with different availability, your order will be held until all items are ready to be shipped together.** Keep this in mind when placing your order. If this is an issue, please contact us at websales@videocraft.com.au to arrange for alternative shipping options.

The Roland VP-42H Video Processor layers and arranges up to four HDMI sources to a single output. Suitable for multi-viewing, presentations, digital signage, and conferences, the VP-42H enables you to switch between preset, layered arrangements of your sources with the push of a button. Use the VP-42H's fluid, motion-based switching to create eye-catching visuals with each upcoming scene automatically positioned and resized in a customizable window. This processor supports multiple video resolutions up to 1080p60, includes a keyer, and accepts still image and logo input via a USB port.

Layering features include three PiP functions plus one PiP with a keyer. Use the VP-42H's web-based browser to scale, crop, zoom, and position input sources by clicking and dragging on your tablet or laptop. Audio features include an internal mixer, RCA outputs for de-embedding audio from your HDMI sources, and RCA inputs for embedding external audio into your HDMI output.

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Processing	4:4:4 (Y/Pb/Pr, RGB), 10-Bit 4:2:2 (Y/Pb/Pr), 10-Bit
Input Connectors	4 x HDMI Type A
Output Connectors	1 x HDMI Type A (Program) 1 x HDMI Type A (Menu)
HDCP Compliant	Yes
Supported Formats & Resolutions	1080p: 59.94/50 1080i: 59.94/50 720p: 59.94/50 576p: 50* 576i: 50* 480p: 59.94* 480i: 59.94* 1920 x 1200/60 RB, 1920 x 1080/60 1600 x 1200/60 1400 x 1050/60 1366 x 768/60 1280 x 1024/60, 1280 x 800/60, 1280 x 720/60 1024 x 768/60 800 x 600/60*
Effects	Layers: x 4 PiP with Keyer: x 1 PiP: x 3
Still Image Support	Internal Memory: x 1 Maximum Size: 1920 x 1200 Pixels Format: Windows Bitmap File (.bmp), 24 bpp, Uncompressed

Sample Rate	48 kHz, 24-Bit
Input Connectors	4 x HDMI Type A 1 x RCA Stereo
Output Connectors	2 x HDMI Type A* 1 x RCA Stereo 1 x 1/8" / 3.5 mm Headphone Stereo
Input Level	-10 dBu (Maximum: +8 dBu)
Input Impedance	15 kOhms
Output Level	Audio Output: -10 dBu (Maximum: +8 dBu) Headphone Output: 72 mW + 72 mW (32 Ohms)
Output Impedance	Audio Output: 1 kOhm Headphone Output: 10 Ohms
Format	HDMI: Linear PCM, 24-Bit, 48 kHz, 2-Ch
Processing	Mixer: 4-Ch (Maximum Delay: 250 ms)

External Connectors	Remote: 1 x RS-232, DB-9 (Male) LAN: 1 x RJ45 USB: 1 x USB Type-A (Future Expansion) USB Memory: 1 x USB Type-A
Functions	Scene Memory: x 10 Test Pattern Generator Test Tone Generator EDID Emulator
Power Supply	AC Adapter
Current Draw	2.1 A
Power Consumption	25 W
Operating Temperature	32 to 104°F / 0 to 40°C
Dimensions (WxDxH)	9.5 x 4.9 x 1.7" / 242 x 125 x 44 mm
Weight	2.6 lb / 1.2 kg
