| General: |
  | Camera type | Interchangeable-lens digital camera |
  | Lens mount | Sony E-mount |
  |  |
  | Image sensor: |
  | Type | APS-C type (23.5 x 15.6mm) Exmor CMOS sensor |
  | Number of pixels (effective) | Approx. 24.2 megapixels |
  | Number of pixels (total) | Approx. 25.0 megapixels |
  | Image sensor aspect ratio | 3:2 |
  | Anti-dust system | Yes |
  |  |
  | Recording system (still images): |
  | Recording Format | JPEG (DCF Ver. 2.0, Exif Ver.2.31, MPF Baseline compliant), RAW (Sony ARW 2.3 format) |
  | Image size (pixels) | 3:2 aspect ratio L: 6000 x 4000 (24M), M: 4240 x 2832 (12M), S: 3008 x 2000 (6.0M) |
  |  | 16:9 aspect ratio L: 6000 x 3376 (20M), M: 4240 x 2400 (10M), S: 3008 x 1688 (5.1M) |
  |  | 1:1 aspect ratio L: 4000 x 4000 (16M), M: 2832 x 2832 (8.0M), S: 2000 x 2000 (4.0M) |
  |  | Sweep Panorama Wide: horizontal 12416 x 1856 (23M), vertical 5536 x 2160 (12M), Standard: horizontal 8192 |
  |  | x 1856 (15M), vertical 3872 x 2160 (8.4M) |
  | Image quality modes | RAW, RAW & JPEG (Extra fine, Fine, Standard), JPEG (Extra fine, Fine, Standard) |
  | RAW output | 14 bit |
  | Picture Effect | 13 types: Posterisation (Colour), Posterisation (B/W), Pop Colour, Retro Photo, Partial Colour (R/ |
  |  | G/B/Y), High Contrast Monochrome, Toy Camera (Normal/Cool/Warm/Green/Magenta), |
  |  | Soft High-key, Soft Focus (High/Mid/Low), HDR Painting (High/Mid/Low), Rich-tone |
  |  | Monochrome, Miniature (Auto/Top/Middle (H)/Bottom/Right/Middle (V)/Left), Watercolour, |
  |  | Illustration (High/Mid/ Low) |
  | Creative Style | Standard, Vivid, Neutral, Clear, Deep, Light, Portrait, Landscape, Sunset, Night Scene, Autumn |
  |  | leaves, Black & White, Sepia, Style Box (1-6), (Contrast (-3 to +3 steps), Saturation (-3 to +3 |
  |  | steps), Sharpness (-3 to +3 steps)) |
  | Dynamic range functions | Off, Dynamic Range Optimiser (Auto/Level (1-5)), Auto High Dynamic Range (Auto Exposure |
  |  | Difference, Exposure Difference Level (1-6 EV, 1.0 EV step)) |
  | Colour space | sRGB standard (with sYCC gamut) and Adobe RGB standard compatible with TRILUMINOS Colour |
  |  |
  | Recording system (movies): |
  | Recording Format | XAVC S / AVCHD format Ver. 2.0 compliant |
  | Video compression | XAVC S: MPEG-4 AVC/H.264 |
  |  | AVCHD: MPEG-4 AVC/H.264 |
  | Audio recording format | XAVC S: LPCM 2ch |
  |  | AVCHD: Dolby Digital (AC-3), 2ch, Dolby Digital Stereo Creator |
  | Image size (pixels) | NTSC XAVC S 4K: 3840 x 2160 (30p, 100M), 3840 x 2160 (24p, 100M), 3840 x 2160 (30p, 60M), 3840 |
  |  | x 2160 (24p, 60M) |
  |  | XAVC S HD: 1920 x 1080 (120p, 100M), 1920 x 1080 (120p, 60M), 1920 x 1080 (60p, 50M), 1920 |
  |  | x 1080 (30p, 50M), 1920 x 1080 (24p, 50M), 1920 x 1080 (60p, 25M), 1920 x 1080(30p, 16M) |
  |  | AVCHD: 1920 x 1080 (60p/28Mbps/PS, 60i/24Mbps/FX, 60i/17Mbps/FH, 24p/24Mbps/FX, |
  |  | 24p/17Mbps/FH) |
  |  | PAL XAVC S 4K: 3840 x 2160 (25p, 100M), 3840 x 2160 (25p, 60M) |
  |  | XAVC S HD: 1920 x 1080 (100p, 100M), 1920 x 1080 (100p, 60M), 1920 x 1080 (50p, 50M), 1920 |
  |  | x 1080 (25p, 50M), 1920 x 1080 (50p, 25M), 1920 x 1080 (25p, 16M) |
  |  | AVCHD:1920 x 1080 (50i, 24M, FX), 1920 x 1080 (50i, 17M, FH) |
  | Slow & Quick motion (S&Q) Record Setting | NTSC mode: 1920x1080 (60p, 30p, 24p) |
  |  | PAL mode: 1920x1080 (50p, 25p) |
  | Slow & Quick motion (S&Q) Frame Rate | NTSC mode: 1fps, 2fps, 4fps, 8fps, 15fps, 30fps, 60fps, 120fps |
  |  | PAL mode: 1fps, 2fps, 3fps, 6fps, 12fps, 25fps, 50fps, 100fps |
  | Picture Profile | Yes (Off / PP1-PP10) Parameters: Black level, Gamma (Movie, Still, Cine1-4, ITU709, ITU709 |
  |  | [800%], S-Log2, S-Log3, HLG, HLG1-3), Black Gamma, Knee, Colour Mode, Saturation, Colour |
  |  | Phase, Colour Depth, Detail, Copy, Reset |
  | Movie functions | Audio Level Display, Audio Rec Level, PAL/NTSC Selector, Proxy Recording (1280 x 720 |
  |  | (Approx. 9Mbps)), TC/UB (TC Preset/UB Preset/TC Format/TC Run/TC Make/UB Time Rec), |
  |  | Auto Slow Shutter, REC Control, Clean HDMI Info. (ON/OFF selectable), Gamma Disp. Assist |
  | Colour space | xvYCC standard (x.v.Colour when connected via HDMI cable) compatible with TRILUMINOS Colour |
  |  |
  | Clean HDMI output | 3840 x 2160 (30p), 3840 x 2160 (25p), 3840 x 2160 (24p), 1920 x 1080 (60p), 1920 x 1080 (60i), |
  |  | 1920 x 1080 (50p), 1920 x 1080 (50i), 1920 x 1080 (24p), YCbCr 4:2:2 8bit / RGB 8bit |
  |  |
  | Media: |
  | Media | Memory Stick PRO Duo, Memory Stick PRO-HG Duo, Memory Stick Micro (M2), SD memory |
  |  | card, SDHC memory card (UHS-I compliant), SDXC memory card (UHS-I compliant), microSD |
  |  | memory card, microSDHC memory card, microSDXC memory card |
  | Slot | Multi slot for Memory Stick Duo/ SD memory card |
  |  |
  | Noise reduction: |
  | Noise reduction | Long exposure NR: On/Off, available at shutter speeds longer than 1 sec., High ISO NR: |
  |  | Normal/Low/Off |
  | Multi Frame NR | Auto/ ISO 100 to 102400 |
  |  |
  | White balance: |
  | Modes | Auto / Daylight / Shade / Cloudy / Incandescent / Fluorescent (Warm White / Cool White / |
  |  | Day White / Daylight) / Flash /Underwater/ Colour Temperature (2500 to 9900K) & colour filter |
  |  | (G7 to M7 (57-step), A7 to B7 (29-step)) / Custom |
  | AWB micro adjustment | G7 to M7 (57-step), A7 to B7 (29-step) |
  | Priority Set in AWB | Yes |
  | Shutter AWB lock | Yes (Shut. Halfway Down/ Cont. Shooting/ Off) |
  | Bracketing | 3 frames, H/L selectable |
  |  |
  | Focus system: |
  | Type | Fast Hybrid AF (phase-detection AF/contrast-detection AF)*1 |
  | Focus point | 425 points (phase-detection AF) / 425 points (contrast-detection AF) |
  | Sensitivity range | EV-2 to EV20 (ISO 100 equivalent with F2.0 lens attached) |
  | AF modes | Automatic AF (AF-A), Single-shot AF (AF-S), Continuous AF (AF-C), Direct Manual Focus (DMF), |
  |  | Manual Focus |
  | Focus area | Wide (425 points (phase-detection AF), 425 points (contrast-detection AF)) / Zone / Center |
  |  | / Flexible Spot (S/M/L) /Expanded Flexible Spot/ Tracking (Wide / Zone / Center / Flexible |
  |  | Spot (S/M/L)/Expanded Flexible Spot) |
  | Focus type with LA-EA3 (sold separately) | Phase-detection/contrast-detection selectable |
  | Other features | Eye-start AF (only with LA-EA2 or LA-EA4 attached (sold separately)), Object Tracking, Eye |
  |  | AF (Right/Left Eye Select), AF micro adjustment with LA-EA2 or LA-EA4 (sold separately), |
  |  | Predictive control, Focus lock, Swt.V/H AF Area, AF Area Regist., Circ. of Focus Point |
  |  |
  | Exposure control: |
  | Metering type | 1200-zone evaluative metering |
  | Metering sensor | Exmor CMOS sensor |
  | Metering sensitivity | EV-2 to EV20 (at ISO 100 equivalent with F2.0 lens attached) |
  | Metering modes | Multi-segment, Center-weighted, Spot (Standard/Large), Entire Screen Avg., Highlight |
  | Exposure modes | AUTO (iAuto/Superior Auto), Programmed AE (P), Aperture priority (A), Shutter-speed |
  |  | priority (S), Manual (M), Movie (Programmed AE (P) / Aperture priority (A) / Shutter-speed |
  |  | priority (S) / Manual (M)), Slow & Quick Motion (Programmed AE (P) / Aperture priority (A) |
  |  | / Shutter-speed priority (S) / Manual (M)), Sweep Panorama, Scene Selection |
  | Scene Selection | Portrait, Sports Action, Macro, Landscape, Sunset, Night Scene, Hand-held Twilight, Night |
  |  | Portrait, Anti Motion Blur |
  | Exposure compensation | +/-5.0 EV (in 1/3 EV or 1/2 EV steps) |
  | AE bracketing | Bracket: Single/Bracket: Cont., 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, |
  |  | 1.0, 2.0 or 3.0 EV increments, with 9 frames, in 1/3, 1/2, 2/3 or 1.0 EV increments. |
  | AE lock | Available with AE lock button. Locked when shutter button is pressed halfway. |
  | ISO sensitivity (Recommended Exposure Index) | Still images: ISO 100-32000 (ISO numbers up to ISO 102400 can |
  |  | be set as expanded ISO range.), AUTO (ISO 100-6400, selectable lower limit and upper limit), Movies: ISO 100-32000 |
  |  | equivalent, AUTO (ISO 100-6400, selectable lower limit and upper limit) |
  |  |
  | Viewfinder: |
  | Type | XGA OLED, 1.0cm (0.39 type) electronic viewfinder (colour) |
  | Total number of dots | 2,359,296 dots |
  | Brightness control | Auto/Manual (5 steps between -2 and +2) |
  | Colour temperature control | Manual (5 steps) |
  | Field coverage | 100% |
  | Magnification | Approx. 1.07x (35mm camera equivalent: Approx. 0.70x) with 50mm lens at infinity, -1m-1 |
  | Diopter adjustment | -4.0 to +3.0m-1 |
  | Eye point | Approx. 23mm from the eyepiece lens, 21.4mm from the eyepiece frame at -1m-1(CIPA standard) |
  | Display | Graphic Display, Display All Info., No Disp. Info., Digital Level Gauge, Histogram |
  | Real-time image-adjustment display | On/Off |
  | Finder Frame Rate selection | NTSC mode: STD 60fps / HI 120fps, PAL mode: STD 50fps / HI 100fps |
  |  |
  | LCD Screen: |
  | Type | 7.5cm (3.0-type) wide type TFT |
  | Total number of dots | 921,600 dots |
  | Touch Panel | Yes |
  | Touch Focus | Yes (Touch Panel/ Touch Pad) |
  | Brightness control | Manual (5 steps between -2 and +2), Sunny Weather mode |
  | Adjustable angle | Up by approx. 180 degrees, Down by approx. 74 degrees |
  | Display | Graphic Display, Display All Info, No Disp. Info, Digital Level Gauge, Histogram, For |
  |  | viewfinder, Monitor Off |
  | Real-time image-adjustment display | On/Off |
  | Focus magnifier | 5.9x, 11.7x |
  | Zebra | Yes (selectable level + range or lower limit as custom setting) |
  | Peaking MF | Yes (Level setting: High/Mid/Low/Off, Colour: White/Red/Yellow/Blue) |
  |  |
  | Other features: |
  | Interval Recording | Yes ( 1-60 sec. interval, 1-9999 shots, AE tracking) |
  | Face detection | Face Priority in AF (On/Off), Face Priority in Multi Metering (On/Off), Registered face priority |
  |  | (On/Off) , Face registration (Max. number of detectable faces: 8) |
  | Auto Object Framing | Yes |
  | Clear Image Zoom | Still images: Approx. 2x, Movies: Approx. 1.5x (4K), Approx. 2x (HD) |
  | Digital zoom |  |
  |  | Smart zoom (still images): M: Approx. 1.4x, S: Approx. 2.0x |
  |  | Digital zoom (still images) L: Approx. 4x, M: Approx. 5.7x, S: Approx. 8x |
  |  | Digital zoom (movies):Approx. 4x |
  | Lens compensation | Peripheral Shading, Chromatic Aberration, Distortion |
  | Others | Smile Shutter: Smile shutter (selectable from 3 steps), Touch Shutter, Touch Focus: Yes (Touch |
  |  | Focus/Touch Pad/Touch Tracking), ISO AUTO Min. SS, Bright Monitoring, Copyright Info, Set |
  |  | File Name, Help guide, Area Setting, Shop Front Mode, Zoom Ring Rotate, Still images |
  |  |
  | Shutter: |
  | Type | Electronically controlled, vertical-traverse, focal-plane type |
  | Shutter Speed | Still images: 1/4000 to 30 sec., Bulb |
  |  | Movies: 1/4000 to 1/4 (1/3-step) |
  |  | NTSC: Up to 1/60 in AUTO mode (up to 1/30 in Auto Slow Shutter mode) |
  |  | PAL: Up to 1/50 in AUTO mode (up to 1/25 in Auto Slow Shutter mode) |
  | Flash sync. speed | 1/160 sec.*2 |
  | Electronic front curtain shutter | Yes, On/Off |
  | Silent Shooting | Yes, On/Off |
  |  |
  | Flash Control: |
  | Control | Built-in flash |
  | Guide No. | 6 (in meters at ISO 100) |
  | Flash coverage | 16mm (focal-length printed on the lens body) |
  | Control | Pre-flash TTL |
  | Flash compensation | +/-3.0 EV (switchable between 1/3 and 1/2 EV steps) |
  | Flash bracketing | 3/5/9 frames selectable. With 3 or 5 frames, in 1/3, 1/2, 2/3, 1.0, 2.0, 3.0 EV increments, with |
  |  | 9 frames, in 1/3, 1/2, 2/3, 1.0 EV increments. |
  | Flash modes | Flash off, Autoflash, Fill-flash, Slow Sync., Rear Sync., Red-eye reduction (On/Off selectable), |
  |  | Wireless control*3, Hi-speed sync*3 |
  | Recycling time | Approx. 4 sec. |
  | External flash | Sony System Flash compatible with Multi Interface Shoe. Attach the shoe adaptor for |
  |  | flash compatible with Auto-lock Accessory Shoe. |
  | FE level lock | Yes |
  | Wireless conrol | Yes (Light signal: Available with Fill-flash, Slow Sync., Hi-speed sync. /Radio signal: Available |
  |  | with Fill-flash, Rear Sync., Slow Sync., Hi-speed sync.) |
  |  |
  | Drive: |
  | Drive modes | Single Shooting, Continuous shooting (Hi+/Hi/Mid/Lo selectable), Self-timer, Self-timer |
  |  | (Cont.), Bracket: Single, Bracket: Cont., White Balance bracket, DRO bracket |
  | Self-timer | 10 sec. delay/5 sec. delay/2 sec. delay/Continuous self-timer (3 frames after 10 sec. delay/5 |
  |  | frames after 10 sec. delay/3 frames after 5 sec. delay/5 frames after 5 sec. delay/3 frames |
  |  | after 2 sec. delay/5 frames after 2 sec. delay)/Bracketing self-timer (Off/2 sec. delay/5 sec. |
  |  | delay/10 sec. delay) |
  | Speed (approx., max.) | Continuous shooting: Hi+: 11 fps, Hi: 8 fps, Mid: 6 fps, Lo: 3 fps |
  | No. of recordable frames (approx.) | JPEG Extra fine L: 99 frames, JPEG Fine L: 115 frames, JPEG Standard L: 116 frames, RAW: 46 |
  |  | frames, RAW & JPG: 44 frames |
  |  |
  | Playback: |
  | Modes | Single (with or without shooting information Y RGB histogram & highlight/shadow warning), |
  |  | 12/30-frame index view, Enlarged display mode (L: 16.7x, M: 11.8x, S: 8.3x, Panorama (Standard): |
  |  | 19.2x, Panorama (Wide): 29.1x), Auto Review (10/5/2 sec.,Off), Image orientation (Auto/ |
  |  | Manual/Off selectable), Slideshow, Panorama scrolling, Folder selection (Date/ Still/ AVCHD/ |
  |  | XAVC S HD/XAVC S 4K), Forward/Rewind (movie), Delete, Protect, Rating, Disp Cont Shoot Grp |
  |  |
  | Interface: |
  | PC interface | Mass-storage, MTP, PC remote |
  | Multi / Micro USB Terminal | Yes |
  | Wireless LAN (built-in) | Wi-Fi Compatible, IEEE802.11b/g/n (2.4GHz band), Playback of still images and movies on |
  |  | smartphones, PCs and TVs |
  | NFC | Yes (NFC Forum Type 3 Tag compatible, One-touch remote, One-touch sharing) |
  | Bluetooth | Yes (Bluetooth Standard Ver. 4.1 (2.4GHz band)) |
  | HD Output | HDMI micro connector (Type-D), BRAVIA Sync (link menu), PhotoTV HD, 4K movie output, |
  |  | 4K still image playback |
  | Multi Interface Shoe | Yes |
  | Others | Microphone terminal (3.5mm Stereo minijack) |
  |  |
  | Audio: |
  | Microphone | Built-in stereo microphone or XLR-K2M / XLR-K1M / ECM-XYST1M (sold separately) |
  | Speaker | Built-in, monaural |
  |  |
  | Print: |
  | Compatible standards | Exif Print, Print Image Matching III, DPOF setting |
  |  |
  | Custom function: |
  | Type | Custom key settings, Programmable Setting (Body 3 sets /memory card 4 sets), My Menu, |
  |  | My Dial, Reg Cust Shoot Set |
  |  |
  | Power: |
  | Battery | Rechargeable battery pack NP-FW50 |
  | Still images | Approx. 360 shots (Viewfinder) / Approx. 410 shots (LCD monitor) (CIPA standard)*9 |
  | Movies | Approx. 70 min (Viewfinder) / Approx. 75 min (LCD monitor) (CIPA standard)*10 |
  |  | Approx. 125 min (Viewfinder) / Approx. 125 min (LCD monitor) (CIPA standard)*11 |
  | External power | AC Adaptor AC-PW20 (sold separately) |
  |  |
  | Weight: |
  | With battery and Memory Stick PRO Duo | Approx. 403g (approx. 14.3 oz. ) |
  |  | Body only Approx. 359g (approx. 12.7 oz.) |
  |  |
  | Dimensions (excluding protrusions) | Approx. 120.0mm x 66.9mm x 59.7mm, Approx. 120.0mm x 66.9mm x 49.9mm (from grip to |
  |  | monitor)/Approx. 4 3/4 x 2 3/4 x 2 3/8 inches, Approx. 4 3/4 x 2 3/4 x 2 inches (from grip to monitor) |
  |  |
  | Operating temperature | Range 32°-104°F / 0-40°C |
