Sony LMD-A240 24 inch LCD Production Monitor

Name: Sony LMD-A240 24 inch LCD Production Monitor
Brand: Sony
SKU: SON-LMDA240
Price: 4306.00 AUD
Availability: InStock

Sony | SKU: SON-LMDA240 | UPC: 4905524961089

$4,306.00 ~~$4,620.00~~

Tax included Shipping calculated at checkout.

Shipping Options

Shipping Methods & Estimated Delivery Times

Australia Post Express Shipping – 1–2 business days within the same state, 1–3 business days interstate.
Australia Post Regular Shipping – 2–4 business days within the same state, 3–6 business days interstate.
StarTrack Express – 2–7 business days, depending on location.
StarTrack Premium – Next business day between capital cities and major metro areas.
Local On-Demand Delivery (Small Orders Only) – Same-day delivery within Melbourne & Sydney metro areas using Uber and Yello.

Shipping Cut-Off Time: Orders placed before 2 PM will typically be processed and dispatched the same day.

Please note: **We ship orders as a single shipment. If your order contains items with different availability, your order will be held until all items are ready to be shipped together.** Keep this in mind when placing your order. If this is an issue, please contact us at websales@videocraft.com.au to arrange for alternative shipping options.

The Sony LMD-A240 24 Inch LCD Production Monitor is a portable, 1920 x 1200 resolution monitor for on set, studio, and broadcast use. The monitor features an IPS LCD display with wide 178° horizontal and vertical viewing angles and provides 3G/HD/SD-SDI, HDMI, and composite inputs, which support NTSC/PAL, 720p, 1080i, and 1080p input signals with frames rates from 24p to 60p. The monitor introduces several new features and upgrades from previous LMD series monitors, including a new low latency automatic I/P conversion, new video processing engine for improved image accuracy, on screen tally, and yoke mounting screw holes. The monitor also provides a wide range of professional monitoring features, such as built-in waveform and vectorscope, focus assist with adjustable colored peaking, time code display, and a Slog2 to Rec 709 LUT.

Panel/Display
Type	IPS LCD
Backlight Technology	LED
Screen Size (Diagonal)	24.1" (61.1 cm)
Effective Picture Size (H x V)	20.41 x 12.76" (51.84 x 32.40 cm)
Resolution	1920 x 1200
Native Aspect Ratio	16:10
Viewing Angle (H/V)	178° / 178°
Normal Scan	0% scan
Color Temperature	D65, D93
Warm-Up Time	Approx. 30 minutes

Input
Video Input	2 x BNC, 3G/HD/SD-SDI 1 x HDMI, HDCP compliant 1 x BNC, Composite (NTSC/PAL)
Audio Input	1 x Stereo mini jack, -5 dBu 47 kohm or higher
Power Input	1 x XLR 4-pin (male), 12 to 17 VDC (output impedance 0.05 ohm or less)
Remote Control	1 x Parallel remote, RJ-45 modular connector 8-pin 1 x Serial remote, RJ-45 modular connector (ETHERNET, 10BASE-T/100BASE-TX)

Output
Video Output	2 x BNC, 3G/HD/SD-SDI, Output signal amplitude: 800 mVp-p ±10% Output impedance: 75 ohm unbalanced 1 x BNC, Composite (NTSC/PAL) loop-though, 75 ohm automatic terminal function
Audio Output	1 x Stereo mini jack, audio monitor output 1 x Stereo mini jack, headphone output 1 x 1.0 W monaural speaker

Formats

3G-SDI (10-bit 4:4:4 YCbCr and 4:4:4 RGB supported)
1080PsF 24/25/30
1080p 24/25/30/
1080i 50/60
720p 50/60

3G-SDI (10-bit 4:2:2 YCbCr supported)
1080p 50/60

HD/SD-SDI
1080PsF 24/25
1080p 24/25/30
1080i 50/60
720p 24/25/30/50/60
575/50i (PAL)
480/60i (NTSC)

HDMI
1080p 24/25/30/50/60
1080i 50/60
720p 50/60
640x480/60p
576/50p
480/60p
575/50i (PAL)
480/60i (NTSC)

Note: 1080/25PsF, 30PsF are displayed as 1080/25PsF, 30PsF on the screen if the payload ID is added to the video signal, or displayed as 1080/50i, 60i if the ID is not added.

PC Signal Compatibility

HDMI input:
640 x 480: 25.175 MHz, fH 31.5 kHz, fV 60 Hz
1280 x 768: 68.25 MHz, fH 47.4 kHz, fV 60 Hz
1280 x 1024: 108 MHz, fH 64 kHz, fV 60 Hz
1360 x 768: 85.5 MHz, fH 47.7 kHz, fV 60 Hz
1440 x 900: 88.75 MHz, fH 55.5 kHz, fV 60 Hz
1680 x 1050: 119 MHz, fH 64.7 kHz, fV 60 Hz
1600 x 1200: 162 MHz, fH 75 kHz, fV 60 Hz
1920 x 1200: 154 MHz, fH 74 kHz, fV 60 Hz

General
Power	100 to 240 VAC, 0.5 to 0.4 A, 50/60 Hz 12 to 17 VDC (4-pin XLR)
Power Consumption	Approx. 51 W (max.) Approx. 45 W (average power consumption in the default status)
Inrush Current	Maximum possible inrush current at initial switch-on (voltage changes caused by manual switching): 45 a peak, 5 A r.m.s (240 VAC) Inrush current after a mains interruption of 5 seconds (voltage changes caused at zero-crossing): 15 A peak, 3 A r.m.s. (240 VAC)
Operating Temperature	32 to 95°F (0 to 35°C) Recommended temperature: 68 to 86°F (20 to 30°C)
Operating Humidity	30 to 85% (no condensation)
Storage Temperature	-4 to 140°F (-20 to 60°C)
Storage Humidity	0 to 90%
Pressure Tolerance	700 hPa to 1060 hPa
VESA Mounting	100 x 100 mm
Dimensions (H x W x D)	Without feet: 15.7 x 22.3 x 3.1" (397.8 x 566.6 x 78.2 mm) With feet: 16.5 x 22.3 x 6.5" (420.3 x 566.6 x 165.0 mm)
Weight	Approx. 16.75 lb (7.6 kg)
