DJI SDR Transmission 2 Wireless Video Transmitter

Name: DJI SDR Transmission 2 Wireless Video Transmitter
Brand: DJI
SKU: DJI-DJISDRTRANS2
Price: 569.00 AUD
Availability: InStock

DJI | SKU: DJI-DJISDRTRANS2 | Barcode: 4000001613434

DJI SDR Transmission Options:

SDR Transmission 2 $569.00 SDR Transmission 2 Combo $999.00

$569.00

Tax included

Store Availability

Melbourne (Burwood) Out of Stock

▼

Out of Stock. Place a Backorder

📍 148 Highbury Road, Burwood, VIC 3125

☎ 03 9273 7500 • Get directions

Sydney (St Leonards) Out of Stock

▼

Out of Stock. Place a Backorder

📍 20/39 Herbert Street, St Leonards, NSW 2065

☎ 02 9462 8600 • Get directions

Shipping Options

Shipping Methods & Estimated Delivery Times

Australia Post Express Shipping – 1–2 business days within the same state, 1–3 business days interstate.
Australia Post Regular Shipping – 2–4 business days within the same state, 3–6 business days interstate.
StarTrack Express – 2–7 business days, depending on location.
StarTrack Premium – Next business day between capital cities and major metro areas.
Local On-Demand Delivery (Small Orders Only) – Same-day delivery within Melbourne & Sydney metro areas using Uber and Yello.

Shipping Cut-Off Time: Orders placed before 1 PM will typically be processed and dispatched the same day.

Please note: **We ship orders as a single shipment. If your order contains items with different availability, your order will be held until all items are ready to be shipped together.** Keep this in mind when placing your order. If this is an issue, please contact us at websales@videocraft.com.au to arrange for alternative shipping options.

DJI SDR Transmission 2 is a versatile wireless video transceiver for stable monitoring on complex productions. It supports DCI 4K/60fps 10-bit HDR video in H.265 at up to 50 Mbps, with Auto Channel 2.0 managing frequencies in busy locations. Low-latency transmission, camera switching without re-pairing, and selectable transmitter or receiver operation suit directors, operators and focus pullers.

Flexible Transceiver Design

DJI SDR Transmission 2 can operate as either a transmitter or receiver, with a switchable design that adapts to different monitoring setups. At 136 grams, its compact body is easy to mount on a camera, rig or other production equipment.

Expanded Connectivity

The Expansion Plate adds one SDI output, one HDMI output and four USB-C ports for flexible monitoring configurations. SDI metadata transmission is supported, while the Transceiver Case provides protection and additional mounting points for car rigs and outdoor setups.

Flexible Power Options

The transceiver supports industry-standard NP-F batteries with an input range of 6.8 to 8.4 V. It can also run from a USB-C Power Delivery charger at 15 V or 9 V and 3 A, or draw power directly from compatible DJI Ronin series gimbals, including the DJI RS 5, RS 4 Pro, RS 4, RS 3 Pro, Ronin 2 and Master Wheels.

DJI SDR Transmission
Weight	Approx. 136 g
Dimensions	76×61×25 mm (L×W×H, excluding antennas and Cold Shoe Adapter)
Ports	HDMI: Input/output USB-C (Top): PD power input/output USB-C (Bottom): DP input/output, PD power input/output, device activation and firmware updates, log export, phone app connection, and connection to the DJI Ronin series, Osmo Action 6, and Osmo Pocket series* devices
Operating Frequency	Non-DFS Frequency Band: 2.400–2.4835 GHz 5.150–5.250 GHz 5.725–5.850 GHz DFS Frequency Band: 5.250–5.350 GHz 5.470–5.725 GHz
Transmitter Power (EIRP)	2.400–2.4835 GHz: < 20 dBm (SRRC/CE/MIC) 5.150–5.250 GHz: < 23 dBm (SRRC/CE/MIC) 5.250–5.350 GHz: < 23 dBm (SRRC/CE/MIC) 5.470–5.725 GHz: < 26 dBm (CE/MIC) 5.725–5.850 GHz: < 30 dBm (SRRC) < 14 dBm (CE)
Maximum Bandwidth	40 MHz
Maximum Encoding Bitrate	50 Mbps
Power Consumption	Standby (no external devices connected): Single Transmitter: Approx. 5.04 W Single Receiver: Approx. 5.31 W 1T1R Transmission: Main Unit: Transmitter approx. 8.52 W, receiver approx. 7.58 W Each Unit With an Expansion Plate (SDI input/output): Transmitter approx. 10.36 W, receiver approx. 8.89 W
Power Supply	USB-C Power Supply Type 1: 15 V, 3 A (PD protocol*) USB-C Power Supply Type 2: 6.8–17.5 V DC NP-F Battery Power Supply Voltage: 6.8–8.4 V
Video I/O Formats	DCI 4K: 23.98/24/25/29.97/30/50/59.94/60fps 4K UHD: 23.98/24/25/29.97/30/50/59.94/60fps 1080p: 23.98/24/25/29.97/30/50/59.94/60fps 1080i (input only on the main unit; input/output on the Expansion Plate): 50/59.94/60fps 720p: 50/59.94/60fps
Audio I/O Formats	Input Audio Format: SDI embedded, HDMI embedded, DP embedded Output Audio Format: 16-bit, 48 kHz, stereo PCM
Video Transmission System	SDR
Minimum Video Transmission Latency	35 ms
Video Coding Format	H.265
Maximum Transmission Distance	Up to 4 km (CE)
Operating Temperature	−10° to 40° C

DJI SDR Transmission Receiver
Weight	Approx. 105 g
Dimensions	76×54×25 mm (L×W×H, excluding Cold Shoe Adapter)
Ports	HDMI: Input/output USB-C (Right): Power supply and DJI RS 5 connection USB-C (Bottom): Power supply, camera control (photo capture and recording start/stop), and connection to DJI Ronin series devices* other than DJI RS 5 SDI: Input/output
Power Supply	USB-C Power Supply Type 1: 15 V/9 V, 3 A (PD protocol*) USB-C Power Supply Type 2: 6.8–17.5 V DC
Operating Temperature	−10° to 40° C

DJI SDR Transmission Expansion Plate
Weight	Approx. 91 g
Dimensions	124×110×49 mm (L×W×H)
Mounting	NATO port 1/4″-20 screw hole × 2 3/8″-16 screw hole HDMI cable clamp USB-C cable clamp
Operating Temperature	−10° to 40° C
